ABH 1865 Self-Latching Top Bolt and Bottom Fire Bolt, Metal Door Application

Let us build your organization a custom and personalized eStore.

Learn More

Standardize materials and improve the purchasing process for your facilities.

ABH 1865 Self-Latching Top Bolt and Bottom Fire Bolt, Metal Door Application

SKU:
ABH 1865
Part #:
Model:
1865-S4
$93.13 - $106.25

Choose product options below to view Shipping Lead Time

(No reviews yet) Write a Review
Adding to cart… The item has been added
California Prop 65 Warning

Product Overview

This self-latching top and bottom fire bolt is for use on a fire rated metal door labeled A, B, C, D and E, door dimensions up to 4'0" x 10'0". The self-latching top bolt latches when the inactive leaf closes and stays latched until it is retracted manually. The bolt automatically engages when the inactive door closes. When the active door is opened, the inactive door stays latched at the top until the top bolt is released by pressing the plunger button on the bolt face. Low (5 lbs. maximum) closing force. Override feature prevents damage to doors or bolt if bolt head is blocked from entering strike. Bolt head rod is adjustable up to 1-1/2". Thermal lock automatically locks the inactive door under high heat conditions due to fire. Bottom fire bolt eliminates need for floor prep. Oversize fire bolt strike hole allows for slight door misalignment. UL listed.

Specifications

  • Door Material
    Metal
  • Fasteners
    8 ea #8 x 3/4" FH Combo Screws, 4 ea. Plastic Anchors
  • Hand
    Non-Handed
  • Material
    Brass, Stainless Steel
  • Type
    Self-Latching
  • Unit of Measure
    Each
  • Weight
    2
