Product Overview
Designed for medium-traffic, commercial applications, the 1131 Series Door Closer is a Grade 1 closer that fully adjusts for sizes 1-6 and easily retrofits on store front entry doors. Common applications also include offices, hotel rooms, assisted living facilities. Full rack and pinion. Arm leverage adjustment. Separate key controlled regulating valves for door closing and latching speed. Valves are captivated to prohibit vandalism. Adjustable backcheck valve is standard.Resources
Warranty Information
25 Years LimitedSpecifications
-
- ADA Compliant
- Yes
-
- Application
- For Offices, Hotel Rooms and Assisted Living Facilities, Medium-Traffic, Commercial
-
- Arm Type
- Regular
-
- BAA Compliant
- Yes
-
- Back Check
- Adjustable
-
- Closer Size
- Adjustable 1-6
-
- Country of Origin
- USA
-
- Cover
- No
-
- Device Type
- Hydraulic
-
- Doors
- Interior
-
- Grade
- Grade 1
-
- Hand
- Non-Handed
-
- Hold Open
- No
-
- Includes
- Parallel Arm Conversion Bracket, Hardware
-
- Mounting Location
- Push or Pull Side
-
- Mounting Style
- Tri Mount
-
- Rated Opening Compliant
- Yes
-
- Screws
- Wood and Machine
-
- Series
- Sargent 1131 Series Door Closers
-
- Standards
- ANSI A156.4, UL and ULC Listed
-
- Through Bolts
- Yes
-
- Unit of Measure
- Each
-
- Width
- 9-3/4" Closer Body
