Falcon 24 Series Rim Electronic Exit Device, Panic

Let us build your organization a custom and personalized eStore.

Learn More

Standardize materials and improve the purchasing process for your facilities.

Falcon 24 Series Rim Electronic Exit Device, Panic

SKU:
FAL EL-24-R
Part #:
Model:
FALMEL24REO326D
$1,456.80 - $1,954.20

Choose product options below to view Shipping Lead Time

(No reviews yet) Write a Review
Adding to cart… The item has been added
California Prop 65 Warning

Product Overview

The 24/25 series heavy-duty architectural push pad exit devices provide quick, easy egress suitable for various applications. Offices, banks, assisted living facilities, retail stores and other commercial buildings have constant traffic, so the exit devices must be able to perform under continual use and abuse. The 24/25 Series exit devices out-perform competitors and are offered at a reasonable price. The ANSI/BHMA Grade 1 certified exit devices feature a sleek, streamlined styling and smart solutions for any building design while assuring egress in case of an emergency. Extruded aluminum construction delivers greater strength and impact resistance. No exposed screws or rivets on the back of the device for a streamlined design and clean lines for a more attractive installation. One trim input design provides maximum versatility and ability to use various trims. Stainless steel push pad cover provides a scratch-resistant pushing surface. Flush-end caps help prevent them from being destroyed or knocked off in abusive situations. Narrow stile center case is ideal for storefront applications with narrow stile aluminum doors. **Aditional options may be available, inquire via chat**

Warranty Information

1 Year Limited

Specifications

  • Application
    Interior or Exterior Doors
  • Bolt
    Stainless Steel Latchbolt
  • Bolt Throw Length
    3/4"
  • Cylinder
    NOT Included
  • Device Type
    Rim
  • Dogging Options
    Hex Key Dogging
  • Door Material
    Wood or Metal
  • Door Thickness
    1-3/4"
  • Duty Weight/Class
    Heavy Duty
  • Fasteners
    All mounting screws are concealed
  • Fire Rated
    Non Rated
  • Grade
    Grade 1
  • Material
    Center case is heavy wrought and sintered metal parts
  • Mounting Location
    40" from CL to finished floor
  • Projection
    2-3/4" maximum, 2" when dogged
  • Rated Opening Compliant
    No
  • Series
    Falcon 24/25 Series Exit Devices
  • Standards
    ANSI 156.3-2001
  • Stiles
    2-1/4" Minimum (3-1/2" Standard)
  • Strike Number
    299
  • Strike Size
    2-7/8"H x 1-1/4"W x 13/16"D
  • Type
    Narrow Stile Pushpad
  • Unit of Measure
    Each
