ABH 0370 Electrified, Heavy Duty Pivot Set, Center Hung

SKU:
ABH E0370
Part #:
Model:
E0370-S1
$265.31 - $345.16

(No reviews yet) Write a Review
Adding to cart… The item has been added

Product Overview

This E0370 Pivot Set includes E0340 Electrified Top Pivot and 0370B Bottom Pivot. Pivot set is centered into the door thickness. Top pivot frame leaf mortises into header, door leaf mortises into top of door and provides electrical power transfer from the frame to the door via (8) 30 AWG wires. Bottom pivot bottom leaf mounts on top of finished floor, door leaf mortises into bottom of door. Reversible installation.

Specifications

  • Duty Weight/Class
    Heavy Duty
  • Hand
    Non-Handed
  • Max. Door Weight
    500 lbs.
  • Max. Door Width
    44"
  • Power Transfer/Wires
    (8) 30 AWG wires
  • Unit of Measure
    Each
  • Weight
    4
