Schlage L Series Mortise Lockset, Faculty/Hotel/Restroom Function

Product Overview

The Schlage L Series has long been the benchmark for mortise locks. The L Series is more than strength and security it offers tremendous flexibility to allow it to meet the needs of most every application. Over 55 functions, 35 lever and knob designs, eight different roses and escutcheons, and a multitude of prep options are just the beginning. 180 degree visibility indicators, advanced motor-driven electrified functions, a universal lock case that supports 10 different functions, and the ability to suite across tubular, exit device, and multipoint locks allow the Schlage L Series to integrate seamlessly into any environment. Expansive list of configurations and options, including retrofit indicators. 50 standard mechanical functions, custom functions also offered. "The Original" universal lock case allows creation of 10 functions from a single lock body. 14 finishes and 33 levers, two knobs, five roses and three escutcheon designs. Supports standard, SFIC and FSIC cylinder formats. Multiple key systems available, open, patented, restricted, geographic exclusive, UL 437. **Additional options may be available, inquire via Chat.**

Resources

Schlage_L_Series_Catalog_102899

Warranty Information

3 Years Limited

Specifications

ADA Compliant

Yes
Action

Deadbolt Actuation by Thumbturn, Inside Knob/Lever Retracts Both Deadbolt and Latchbolt
Additional Information

Inside Lever Always Free for Immediate Egress
Application

For Exterior, Interior, New Construction, Retrofit Applications
BAA Compliant

Yes
Bolt Throw Length

3/4" (19mm) Latchbolt, 1" (25.5mm) Deadbolt
Country of Origin

Mexico
Device Type

Heavy Duty Traffic, Standard, Mechanical
Door Thickness

1-3/4" (44 mm) Standard
Dust Box

Plastic
Fire Rated

180 Min
Function

Faculty/Hotel/Restroom - Latchbolt Retracted by Outside Key or Inside Knob/Lever; Outside Knob/Lever Always Fixed
Grade

Grade 1
Includes

Hardware
Keyway

Keyed
Lock Face Size

8" x 1-1/4"
Metric Size

113 mm x 154 mm x 25 mm (case dimensions)
Rated Opening Compliant

Yes
Series

Schlage L Series Mechanical Mortise Locks
Size

4-7/16" x 6-1/16" x 1" (case dimensions)
Standards

ANSI/BHMA A156.13-2012, Exceeds 1,000,000 ANSI Cycles
Strike

1-3/16" (30 mm) Lip to Center
Strike Height

4-7/8 (124mm)
Strike Type

ANSI Curved Lip Strike
Strike Width

1-1/4" (32mm)
Unit of Measure

Each
Weight

6.3
