Product Overview
Extended Battery Modules (EBMs) from CyberPower, for select Smart App Uninterruptible Power Supply (UPS) models, ensure extended battery runtimes during power outages. Each rack/tower convertible Extended Battery Module (EBM) takes up 2U or 3U of rack space, depending upon the model, and can be installed in a tower form factor to match the UPS. The DC plug-and-play power connectors allow for daisy-chaining additional EBMs to an UPS system. The EBMs compatible with Smart App Online UPSes also have a built-in battery charger, providing Fast Charge Technology to quickly restore the backup power supply to full capacity Every CyberPower EBM has a three-year warranty.
Warranty Information
3 Years Limited
Specifications
- Action6 Hour Recharge Time
- Battery12V/9Ah (8) Sealed Lead-Acid Battery
- ColorBlack
- Country of OriginCN
- Device TypeRack/Tower
- Frequency50 Hz – 60 Hz
- Input Voltage100 VAC – 240 VAC
- Metric Size43.43W x 8.64H x 50.04D (cm)
- Mounting StyleThis EBM takes 2U of rack space and can be installed in either a rack or tower configuration to match the UPS form factor
- Operating Temperature32 – 104 °F (0 – 40 °C)
- Output Voltage48V/70A
- Size17.1W x 3.4H x 19.7D (in)
- StandardsRoHS Compliant; CE, RCM , UL1778, cUL, FCC Class B, VCCI
- Unit of MeasureEach
- Use WithUPS systems: PR1000LCDRTXL2UA, PR1500LCDRTXL2U, PR1500RTXL2U, PR2000RTXL2U, PR2200LCDRTXL2U, PR2200RTXL2U, PR3000LCDRTXL2U, PR3000RTXL2U, OR1500LCDRTXL2U, and OR2200LCDRTXL2U
- Weight66.2 lbs. (30.03 kgs)
