Corbin Russwin ML2055 Heavy Duty Mortise Lockset, Lockbody Only, Classroom (F05) Function
Corbin Russwin ML2055 Heavy Duty Mortise Lockset, Lockbody Only, Classroom (F05) Function

Let us build your organization a custom and personalized eStore.

Learn More

Standardize materials and improve the purchasing process for your facilities.

Corbin Russwin ML2055 Heavy Duty Mortise Lockset, Lockbody Only, Classroom (F05) Function

SKU:
CR ML2055 LB
Part #:
Model:
COR300ML2055KK605
Was: $653.09
Now: $421.25

Choose product options below to view Shipping Lead Time

(No reviews yet) Write a Review
Reset Selections

Adding to cart… The item has been added

Related Products

Product Overview

The ML2000 Series is a Grade 1 mortise lock designed to meet the rigors of high-traffic commercial, institutional, industrial and government applications. Constructed of heavy-gauge steel, the lockbody features our patented Quick Reversible latchbolt, and a 1" stainless steel deadbolt. A wide variety of trim designs and functions and a 10-year warranty lend to the ML2000's versatility and reliability, making it the ideal choice for use in offices, schools, hospitals, hotels and other high-use applications. Can be used with new or existing Corbin Russwin key systems. Provides life safety and security in a single door prep, saving the additional cost of a deadlock. Through-bolted trim designs for proper alignment and increased security.

Resources

Warranty Information

10 Year Limited

Specifications

  • Action
    Latchbolt by grip either side, unless outside grip is locked by key outside. Latchbolt by key when outside grip locked. Auxiliary latch deadlocks latchbolt. Inside grip always free. Outside grip remains locked unless unlocked by key.
  • BAA Compliant
    Yes
  • Backset
    2-3/4" (70mm)
  • Bolt
    2-Piece Mechanical with Anti-Friction Insert, 5/8" (16 mm) x 1" (25 mm) Latchbolt; One-Piece Stainless Steel, 19/32" (15 mm) x 1-1/4" (32 mm) Deadbolt
  • Bolt Throw Length
    3/4" (19mm) Latchbolt, 1" (25.5mm) Deadbolt
  • Country of Origin
    USA
  • Door Thickness
    1-3/4"
  • Duty Weight/Class
    Heavy Duty
  • Face Shape
    Accommodates Flat Doors and Doors Beveled 1/8" (3 mm) in 2" (51 mm)
  • Faceplate Depth
    3/32" (2 mm)
  • Faceplate Height
    8" (203 mm)
  • Faceplate Width
    1-1/4" (32 mm)
  • Fire Rated
    Non Rated
  • Function
    Classroom (F05)
  • Grade
    Grade 1
  • Hand
    Field Reversible
  • Includes
    Lock Case, Armored Front, Strike and Screw Pack
  • Keyway
    Less Cylinder
  • Rated Opening Compliant
    Yes
  • Screws
    Wood/Machine Screws
  • Series
    Corbin Russwin ML2000 Series Mortise Locks
  • Size
    Lock Case: 5-7/8" (149 mm) x 4" (102 mm) x 15/16" (24 mm)
  • Standards
    ANSI/BHMA A156.13 Series 1000, Meets A117.1 Accessibility Code, Federal Meets FF-H-106C
  • Strike
    ANSI Straight Lip
  • Strike Height
    4-7/8" (124mm)
  • Strike Number
    236L72018
  • Strike Size
    1-1/8" (29 mm) Lip to Center
  • Strike Type
    ASA
  • Strike Width
    1-1/4" (32 mm)
  • Type
    Lockbody Only
  • Unit of Measure
    Each
