Alarm Lock Trilogy DL1200 Narrow Stile Exit Device Trim, 100 Users
Alarm Lock Trilogy DL1200 Narrow Stile Exit Device Trim, 100 Users

Let us build your organization a custom and personalized eStore.

Learn More

Standardize materials and improve the purchasing process for your facilities.

Alarm Lock Trilogy DL1200 Narrow Stile Exit Device Trim, 100 Users

SKU:
AL DL1200ET
Part #:
Model:
ALA100DL1200ET10B
Was: $1,024.25
Now: $629.91

Choose product options below to view Shipping Lead Time

(No reviews yet) Write a Review
Reset Selections

Adding to cart… The item has been added

Related Products

Product Overview

Alarm Lock's Trilogy narrow stile exit device trim locks for aluminum door retrofits. Adds vandal-resistant keyless access to panic exit doors. Protects storefronts and managed properties 24/7. Up to 2000 users supported with 3-5 digit access codes and multilevel user hierarchy. Designed with all-metal, vandal-resistant 12-button keypads. Easily installs on most aluminum glass doors. Works with Marks USA M8800, Von Duprin (Von 33 LH (RHR) only), Arrow, DCI and Corbin panic devices.

Resources

Specifications

  • Action
    Electronic Keyless Access
  • Battery
    2 lithium 3V batteries
  • Depth
    1-5/8"
  • Device Type
    Narrow
  • Door Material
    Aluminum or Glass
  • Grade
    Grade 1
  • Hand
    Field Reversible
  • Handle Type
    Lever
  • Height
    14-3/8"
  • Keypad Type
    12 Button Programmable
  • Keys
    All metal
  • Lights
    LED
  • Material
    Brass/Bronze Base
  • Number of Users
    100
  • Operating Temperature
    -31-151 deg F (-35-66 deg C)
  • Power
    Battery
  • Programmer/
    Programming
    Not Included
  • Reader Technology
    Keypad Only
  • Standards
    UL Listed, CE
  • Stiles
    1-3/4" Thick
  • Type
    Exit Device Trim
  • Unit of Measure
    Each
  • Use With
    Marks USA M8800, .Von Duprin (Von 33 LH (RHR) only), Arrow, DCI and Corbin panic devices
  • Weight
    6.5
  • Width
    1-3/4"
