ABH A140 Full Mortise Continuous Gear Hinge

Part #:
Model:: A140HD-79B

$68.51 - $171.54

Choose product options below to view Shipping Lead Time

(1 review) Write a Review

Reset Selections

This item is not eligible for return

Quantity

Adding to cart… The item has been added

Product Overview

This is a full concealed, heavy duty, aluminum continuous gear hinge with a 3/32" door inset. Door edge protector lip; for use on a 1-3/4" thick door. Fire rated for use on metal swing type doors rated up to 90 minutes and wood swing type doors up to 60 minutes. Continuous hinges alleviate most common alignment problems.

Resources

Specifications

Door Thickness

1-3/4" (44 mm)
Fasteners

12-24ea 7/8" undercut self-drilling, thread forming tek machine screws
Hand

Non-Handed
Hinge Type

Continuous Hinge
Max. Door Width

48"
Mounting Style

3/32" Door Inset
Rated Opening Compliant

Yes
Series

A140 Aluminum Continuous Gear Hinges, Full Mortise
Unit of Measure

Each
Weight

7

1 Review

5
Continuous gear hinge

Posted by Norman on Jan 21st 2023

This was a great item it was easy to install and easy to order. Door swings nicely and does not drag.my customer was very pleased.
